TPI Linear Guide 30-90W Stained Glass Cutting Machine Irregular Glass Cutting With Water Cooling

TPI Linear Guide 30-90W Stained Glass Cutting Machine Irregular Glass Cutting With Water Cooling

  • High Light

    Irregular Glass Cutting Machine

    ,

    Water Cooling Glass Cutting Machine

    ,

    Stained Glass Cutting Machine

  • Linear Guide Brand
    TPI
  • Drive Motor
    XY Linear Motor + Optical Grating Scale
  • Working Frequency
    50HZ/60HZ
  • Key Selling Points
    Ultra Fast Picesecond
  • Drive Motor
    XY Linear Motor + Grating Ruler
  • Laser Power
    30/50/60/75/80/90w
  • Chipping
    ≤5μm
  • Splitting Laser Source Cooling Method
    Water Cooling
  • Place of Origin
    China
  • Brand Name
    CKD
  • Certification
    ISO CE
  • Model Number
    CKD-DP6070C
  • Minimum Order Quantity
    1
  • Price
    Negotiated
  • Packaging Details
    Wooden vacuum packaging
  • Delivery Time
    15-45 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    50 sets per month

TPI Linear Guide 30-90W Stained Glass Cutting Machine Irregular Glass Cutting With Water Cooling



Product Description:CKD E Catalog2310.pdf

  1. High-Power Picosecond Laser Source: Utilizes a powerful laser with picosecond pulse duration for exceptional precision in cutting.
  2. Custom-Designed Glass Cutting Head: Features a proprietary cutting head with high-quality imported lenses, ensuring a fine beam and extended focal depth.
  3. Versatile Cutting Capabilities: Supports both integrated and separate cutting and breaking operations, providing flexibility in processing.
  4. Premium Linear Motors and Grating Scales: Equipped with top-tier linear motors for X/Y axes and precise 0.1μm German digital grating scales.
  5. Advanced Motion Control: Incorporates a standard PSO function for consistent laser spot spacing and precise motion control.
  6. Accurate Positioning System: Includes a positioning CCD and telecentric lenses for exact recognition of circular and cross markers.
  7. High-Quality Electrical Components: Uses electrical parts from Schneider Electric, a renowned French manufacturer.
  8. Reliable Power Supply: Powered by a switching power supply from Mean Well, Taiwan, ensuring stable performance.
  9. Thick Material Cutting: Capable of processing materials up to 19mm in thickness with high efficiency.
  10. Stable and Precise Base: The motor and optical platforms are supported by a natural marble base, enhancing stability and precision in operations.
    TPI Linear Guide 30-90W Stained Glass Cutting Machine Irregular Glass Cutting With Water Cooling 0

Features:

  1. Superior Cut Quality: The process achieves a premium surface finish on the cut material.
  2. Edge Uniformity: The cuts maintain consistent edge widths without tapering, ensuring parallel surfaces.
  3. Burr-Free Cutting: Leaves smooth edges with no burrs, eliminating the need for deburring.
  4. Minimal Chipping: Produces very little chipping at the edges of the material.
  5. Cost-Effective Operation: The equipment operates with low costs, making it economical.
  6. High Production Efficiency: Allows for a high volume of material processing in a given timeframe, boosting productivity.
  7. Low Consumables and Energy Efficient: Uses fewer consumables and is energy-saving.
  8. Fast Cutting for Irregular Shapes: Capable of high-speed cutting of materials in irregular shapes.
  9. Environmentally Friendly: The process generates no pollutants, maintaining a clean operation.
  10. Dust and Wastewater Free: Produces no dust or wastewater, promoting an eco-friendly cutting process.



Technical Parameters:





Specification Description
Cooling Method Water cooling
Pulse Width <10ps
Pulse Frequency 1Hz - 1000kHz
Wavelength 1064nm
Beam Quality M^2 < 1.2
Power 50W (options: 10W, 20W, 30W, 60W, 80W, etc.)
Laser Type Infrared picosecond pulse laser
Drive Motor XY Linear Motor + Optical Grating Scale
Positioning Accuracy ±2um
Repeatability ±1.5um
Acceleration 1G
Linear Speed Up to 1000mm/s
Cutting Speed Adjustable from 0-500mm/s
Cutting Thickness Ultra-clear glass single cut ≤19mm, Blue glass double cut ≤19mm
Minimum Cutting Burr ≤5um
Cutting Precision ±0.01mm
X/Y Cutting Range 610×700mm
Laser Type RFC02 (Radio Frequency CO2)
Cooling Method Water cooling
Wavelength 10.6μm
Power 150W (options: 250W/350W)
Pulse Frequency 1-100kHz
Weight Approximately 3500KG / 40000KG
Machine Dimensions (Option 1) Length 2550mm x Width 2080mm x Height 1960mm
Machine Dimensions (Option 2) Length 2150mm x Width 2080mm x Height 1960mm
Voltage, Power <8KW, AC220V



Applications:



Application Industries and Types of Glass Used
Glass Processing Industry

Glass processing is a highly versatile industry that caters to various applications. Glass is used extensively in sectors such as the automobile, communication media, home appliance and new energy industries.

Optic/UTG/Willow/Brittle Biomedical Glass

Optic, UTG (ultra-thin glass), Willow and brittle biomedical glass are some of the glass types that are used in the biomedical industry. Glass is used for manufacturing of precision instruments in biomedical industry.

Real Estate Industry

Glass is an essential component of architectural decoration used in the real estate industry. Bathroom glass is a common use case in this industry.

Automobile Industry

Glass is essential for manufacturing cars and is used extensively in the automobile industry. Car glass and instrumentation panel glass are two types of glass commonly used in this sector.

Communication Media Industry

Mobile and watch sapphire covers, camera and CCTV lens glass are some of the types of glass used extensively in the communication media industry.

Home Appliance Industry

Glass panels are widely used in home appliances for aesthetic and functional purposes. Glass is also used extensively in the lighting industry.

New Energy Industry

Photovoltaic glass is widely used in the new energy industry. It is used in the manufacturing of solar panels that are used for generating electricity.







Support and Services:



Installation and commissioning: Our professional technical team will go to the customer's site to install and commission the equipment to ensure that the laser equipment is put into use in the shortest time and reaches the best working condition.

Operation training: Provide customers with detailed operation training courses, including basic operation of the equipment, common problem solving and safe use specifications, to ensure that operators can master the use of the equipment.

Technical support: We provide 24-hour technical support services 7 days a week, and promptly solve technical problems encountered by customers during use through telephone, email or remote connection.

Maintenance: Regularly maintain and preventive maintenance for customers' equipment to ensure long-term stable operation of the equipment. Our maintenance services cover hardware and software parts, and quickly respond to customers' maintenance needs.

Spare parts supply: Provide original spare parts to ensure that high-quality replacement parts can be used during equipment maintenance, extend the service life of the equipment, and reduce downtime.

Upgrade and transformation: According to customer needs, upgrade and transform existing equipment to improve equipment performance and meet new production requirements.

Customized services: According to the special needs of different customers, provide customized solutions, including equipment design, development and debugging, to ensure that customers' personalized production needs are met.

On-site service: When equipment fails, our service engineers can quickly go to the site to diagnose and repair it to ensure that production is not affected.
