Maximize Your Glass Cutting Efficiency with Our Cutting-Edge Laser Glass Cutting Machine  To Accuracy±0.01mm

Maximize Your Glass Cutting Efficiency with Our Cutting-Edge Laser Glass Cutting Machine To Accuracy±0.01mm

  • Key Selling Points
    Ultra Fast Picesecond
  • Cutting Thickness
    Ultra-clear Glass Single Cut ≤19mm, Blue Glass Double Cut ≤19mm
  • Mobility
    Equipped With Heavy-duty Wheels For Easy Movement And Repositioning, With Locking Mechanisms For Stability
  • Brand
    CKD
  • Safety Features
    Includes Emergency Stop Button, Protective Cover, Laser Safety Windows, And Automatic Power-off When The Cover Is Open For Safe Operation.
  • Minimum Cutting Burr
    ≤5μm
  • Drive Motor
    XY Linear Motor + Grating Ruler
  • Laser Power
    30/50/60/75/80/90w
  • Accuracy
    ±0.01mm
  • Accuracy Of Segmentation
    ±0.01mm
  • Linear Speed
    Up To 1000mm/s
  • Cutting Speed
    0-20m/min
  • Linear Guide Brand
    TPI
  • Worktable Size
    1300mm X 2500mm
  • Working Table
    Honeycomb/Aluminum Blade
  • Type Of Cooling
    Water-cooling
  • Cooling System
    Water Cooling
  • Safety Protection
    High Safety
  • Cooling Method
    Water Cooling
  • Wavelength
    1064nm
  • Cutting Width
    0.03-25mm
  • Graphic Format
    PLT/DXF/BMP/JPG/GIF/PNG/TIF
  • Pulse Frequency
    1Hz - 1000kHz
  • Place of Origin
    China
  • Brand Name
    CKD
  • Certification
    ISO CE
  • Model Number
    CKD-DP6070C-50E CKD-DP6070C-60E CKD-DP6070C-80TE CKD-DP6070C-50ECKD-DP6070S-50E CKD-DP6070S-60E CKD-DP6070S-80TE CKD-DP6070S-80ECKD-DP6070D-50E CKD-DP6070D-60E CKD-DP6070D-80TE CKD-DP6070D-80ECKD-SP6070S-50E CKD-SP6070S-60E CKD-SP6070S-80TE CKD-SP6070S-80E
  • Minimum Order Quantity
    1
  • Price
    Negotiated
  • Packaging Details
    Wooden vacuum packaging
  • Delivery Time
    25-45 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    60sets per month

Maximize Your Glass Cutting Efficiency with Our Cutting-Edge Laser Glass Cutting Machine To Accuracy±0.01mm

Product Description:

The Thick Glass Laser Cutting Machine is a cutting-edge piece of equipment designed for precision cutting of thick glass materials with utmost accuracy and safety. With cutting precision of ±0.01mm and cutting accuracy of ±0.01mm, this optical glass Laser Cutting Machine ensures that every cut is made with high precision and consistency.

Safety is a top priority with this machine, as it comes equipped with various safety features to ensure safe operation at all times. The machine includes an Emergency Stop Button for immediate halting of operations in case of emergencies. Additionally, a Protective Cover is provided to safeguard the user from any potential hazards during the cutting process. The Laser Safety Windows are designed to protect the user from exposure to the laser beam, further enhancing the safety measures in place. Moreover, the machine is equipped with an Automatic Power-off feature that activates when the cover is open, ensuring safe operation and preventing any accidents.

With a cutting width ranging from 0.03mm to 25mm, this Environmental Protection Glass Laser Cutting Machine offers versatility in handling various glass cutting tasks with different thicknesses. The machine operates at a wavelength of 1064nm, which is optimal for cutting thick glass materials with precision and efficiency.

Whether you are working on intricate glass designs or industrial glass cutting projects, the Thick Glass Laser Cutting Machine is the ideal solution for achieving precise cuts with minimal margin of error. Its advanced features and safety mechanisms make it a reliable and convenient tool for professionals in the glass cutting industry.



Features:

  • Product Name: Laser Glass Cutting Machine
  • Beam Quality: M² < 1.2
  • Cutting Area: 400mm*500mm/ 600*700mm/ 600*900mm
  • Support image and text formats: AI PLT DXF BMP Dst DWg LAS DXP
  • Work Size: 610*700mm X 2 Customizable
  • Laser Type: Infrared Picosecond


Technical Parameters:

Splitting laser source Power 150W (options: 250W/350W)
Splitting laser source Wavelength 10.6µm
Minimum Cutting Burr ≤5μm
Positioning Accuracy ±2μm
Applicable Materials Ultra Clear Class, Plain White Glass High Borosilicate Glass, Quartz Glass Optical Glass, Cover Glass, Camera Glass Cover, Etc. Phone Glass Cover, Car Glass, Camera Glass Cover, Etc. LCD Screen, K9 Glass, Filter Cutting, Mirror Cutting, Etc.
Noise Level Operating Noise Level Is 70dB, With A Built-in Silencing System, Suitable For Low-noise Environments.
Laser wavelength 1064nm
Wavelength 1064nm
Applicable Industries Glassware Industry: Optical Glass, K9 Glass, And Ultra-thin Glass Houseware Industry: High-borosilicate Glass, Quartz Glass, Sanitary Ware Glass Vehicle Industry: Automotive Glass, Car Windshield, Etc. New Energy: Photovoltaic Glass Home Appliance: Home Appliance Glass, Panel Lighting Glass Real Estate: Architectural Decoration, Bathroom Glass, Etc
Cutting Width 0.03-25mm


Applications:

Product Application Occasions and Scenarios for the CKD optical glass Laser Cutting Machine:

The CKD optical glass Laser Cutting Machine, available in models CKD-DP6070C-50E, CKD-DP6070C-60E, CKD-DP6070C-80TE, CKD-DP6070C-50ECKD-DP6070S-50E, CKD-DP6070S-60E, CKD-DP6070S-80TE, CKD-DP6070S-80ECKD-DP6070D-50E, CKD-DP6070D-60E, CKD-DP6070D-80TE, CKD-DP6070D-80ECKD-SP6070S-50E, CKD-SP6070S-60E, CKD-SP6070S-80TE, CKD-SP6070S-80ECKD-SP6070D-50E, CKD-SP6070D-60E, CKD-SP6070D-80TE, CKD-SP6070D-80ECKD-SP6070C-50E, CKD-SP6070C-60E, CKD-SP6070C-80TE, CKD-SP6070C-80E, is suitable for various occasions and scenarios.

Originating from China and certified with ISO CE, this cutting machine has a minimum order quantity of 1 and offers negotiable pricing. The packaging details include wooden vacuum packaging, with a delivery time of 25-45 days and payment terms of L/C, T/T. With a supply ability of 60 sets per month, the CKD optical glass Laser Cutting Machine is equipped with Drive Motor XY Linear Motor + Optical Grating Scale.

Capable of cutting Ultra-clear Glass Single Cut ≤19mm and Blue Glass Double Cut ≤19mm, this machine ensures precision cutting with an accuracy of ±0.01mm. The cutting speed is adjustable from 0-500mm/s, while the linear speed can reach up to 1000mm/s.

Furthermore, the CKD optical glass Laser Cutting Machine is ideal for cutting optical glass, stained glass, and various other materials with high precision and efficiency.



Customization:

Product Customization Services:

Brand Name: CKD

Model Number: CKD-DP6070C-50E CKD-DP6070C-60E CKD-DP6070C-80TE CKD-DP6070C-50ECKD-DP6070S-50E CKD-DP6070S-60E CKD-DP6070S-80TE CKD-DP6070S-80ECKD-DP6070D-50E CKD-DP6070D-60E CKD-DP6070D-80TE CKD-DP6070D-80ECKD-SP6070S-50E CKD-SP6070S-60E CKD-SP6070S-80TE CKD-SP6070S-80ECKD-SP6070D-50E CKD-SP6070D-60E CKD-SP6070D-80TE CKD-SP6070D-80ECKD-SP6070C-50E CKD-SP6070C-60E CKD-SP6070C-80TE CKD-SP6070C-80E

Place of Origin: China

Certification: ISO CE

Minimum Order Quantity: 1

Price: Negotiated

Packaging Details: Wooden vacuum packaging

Delivery Time: 25-45 days

Payment Terms: L/C, T/T

Supply Ability: 60 sets per month

Acceleration: 1G

Whether CNC: Yes

Name: Glass Cutting And Splitting Machine (All-in-One)

Wavelength: 1064nm

Keywords: Stained glass cutting machine, Small glass laser cutting machine, Irregular glass cutting



Support and Services:

Our Product Technical Support and Services for the Laser Glass Cutting Machine include:

- Installation and setup guidance for the machine

- Training sessions for operating the equipment effectively

- Troubleshooting assistance for any technical issues that may arise

- Regular maintenance recommendations to ensure optimal performance
