Handheld Portable 50W CO2 Laser Marking Machine
For Wood Leather Clothes Plastic
The main processing object is non-metal , widely used in food packaging , pharmaceutical packaging , architectural ceramics , clothing accessories , leather , fabric cutting, craft gifts , rubber products , electronic components packaging , shell nameplate and so on. Suitable for paper , wood , glass , leather and other materials .
* All set imported metal sealed laser system, easy to install and operation.
* High precision, high speed, marking clear, strong permanent
* Low power consumption, cost effective and long life, convenient to maintenance.
* Integrated and compact structure
* Imported metal tube, stable and long life.
* Versatile marking software is compatible with Coreldraw,AutoCAD,Photoshop.
* Support PLT, DXF, BMP, PCX, JPG, common vector and bitmap graphics, date marking supporting, serial number, bar code, 2D code,
incrementing serial No., automatic jump codes, etc.
* Excellent for long-lasting operation
* No pollution and consumption
|
Model
|
Transon series
|
Cooling Mode
|
Air Cooling
|
|||
|
Power:
|
20W/30W/50W/60W/100W
|
Marking Speed
|
8000mm/s
|
|||
|
Laser Source
|
Synrad/Coherent/Davi
|
Minumum Line Width
|
0.015mm
|
|||
|
Pulse Frequency
|
1-25Khz/1-100Khz
|
Minumum Character
|
0.2mm
|
|||
|
Field Lens Brands
|
Singapore Wavelength
|
Laser Wavelength
|
1064μm
|
|||
|
Marking Area:
|
110*110mm / 140*140mm/ 175*175mm/210*210mm/300*300mm
|
Operating Environment
|
5℃-45℃, clean or dust-free
|
|||
|
Control Card
|
JCZ Brand EZCAD
|
Power Supply
|
AC220V or 110V plug
|
|||
|
Operating System
|
Win XP /7/ 8/ 10 (32 bit, 64bit)
|
Warranty
|
2 years
|
|||
Product details
HAND LFTING
Manual lifting design simple and convenient operation , laser focus distance can be adjusted accordingly .
GALVANOMETER SCANNER
It is equipped with automatic scanning system , stable output , fast speed , high precision marking .
FIELD LENS
Laser focusing lens provides precise laser focusing performance . Standard working area of field lens is 100"100mm .
RED DOT POINTER
Inner red dot pointer can indicate the real position of the laser beam , make marking more accurate .
CONTROL BUTTONS
Humanized control buttons , easy to operate .
SCALE COLUMN
500mm ruler scale can help user adjust the height of different marking object easily .
WORKTABLE
Worktable with hole make it easy to position .
CO2 RF LASER DEVICE
CO2 radio frequency laser tube adopts air-cooled design , can have thin laser beam, better marking effect , can make marking more convenient . It has long life span, fast speed , fine lines and stable performance , can be widely applied in production line .
CONTROL CABINET
Control cabinet with handle, can be moved easily .
Our laser machines package include 3 layers :
1 , Outside package : Polywood case with metal belt
2 , Middle package : We use foam to cover the machine .
3 , Inner package : We use waterproof plastick bag to cover all the machine .
Q1 : Are you a factory or a trading company ?
A : We are a manufacturer with our own professional R&D team and experienced after-sales service team .
Q2 : How to get the most suitable machine and best price ?
Please tell us what's material you want to marking? And what is your target price? Then we will recommend the most suitable model and the best price for you .
Q3 : If we don't know how to use the machine,can you teach us ?
There is a U disc send together with the machine including machine install video , some video of how to use machine , user manual and software user manual . 99% users can know how to operate it . In case anything need help , please contact us anytime .
1) Online call or video call ( Email , Skype , Whatsapp , Phone )
2)Remote desktop software ( Team viewer )
3)Instructions and notes on the use of the equipment
4) Remote teaching : All our equipment is equipped with a remote control system , so if your operators are not clear or familiar with it , we realize a remote system to teach you the full operation until you can use it and can assist you remotely when you need it subsequently .
Our products are sold all over the world, you can rest assured.
