1064nm Jewelry Laser Welding Machine Accurate Precise For Fine Jewelry Making

1064nm Jewelry Laser Welding Machine Accurate Precise For Fine Jewelry Making

  • Highlight

    1064nm Jewelry Laser Welding Machine

    ,

    Accurate Jewelry Laser Welding Machine

    ,

    Precise Jewelry Laser Welding Machine

  • Welding Depth
    0.1-3mm
  • Dimension
    520*300*270 Mm
  • Laser Pulse Frequency
    1.0~10.0Hz Continuously Adjustable
  • Max Single Pulse Energy
    40J/100J
  • Laser Spot Diameter
    0.1-3mm
  • Product Name
    Tabletop Jewelry Laser Welding Machine
  • Laser Power
    100W/200W
  • Laser Pulse Width
    0.1-10ms
  • Warranty
    One Year
  • Laser Frequency
    1.0~10.0Hz Continuously Adjustable
  • Cooling Method
    Water Chiller Hanli
  • Positioning Accuracy
    +/-0.02mm
  • Laser Wavelength
    1064nm
  • Voltage
    220V/110V Optional
  • Machine Dimension
    Ø295mm X H282mm
  • Wooden Package Dimension
    40x45x48CM
  • Machinery Test Report
    Provided
  • Application
    Jewelry Welding
  • Laser Type
    Fiber Laser
  • Lasre Power
    150 Watts
  • Shield Gas Supply
    One Line Quick Connection
  • Welding Speed
    2-8m/min
  • Observation System
    Microscope CCD Camera Optional
  • Place of Origin
    China
  • Brand Name
    CKD
  • Model Number
    CW-J4
  • Minimum Order Quantity
    1 set

1064nm Jewelry Laser Welding Machine Accurate Precise For Fine Jewelry Making

Product Description:

The Jewelry Laser Welding Machine operates at a laser wavelength of 1064nm, which is perfect for welding precious metals like gold, silver, and platinum. It has a laser pulse frequency of 1.0~10.0Hz, which is continuously adjustable to suit different welding requirements. This feature makes it possible to control the amount of heat applied to the workpiece, resulting in precise and accurate welds.

The Jewelry Laser Welding Machine has a water cooling system that ensures the laser remains at a constant temperature during operation. This cooling system also helps to extend the lifespan of the machine. The machine has a weight of 35KG, making it compact and easy to move around. This feature is particularly useful for jewelers who need to work on different pieces of jewelry in different locations.

The Jewelry Laser Welding Machine comes in two models, with laser power options of 100W and 200W. These models are designed to suit different welding requirements, and the user can choose the one that best fits their needs. The 100W model is suitable for small and delicate repairs, while the 200W model is ideal for larger, more complex welding jobs.

The Jewelry Laser Welding Machine is easy to use and requires minimal training. It has a user-friendly interface that allows the user to adjust the laser pulse frequency, laser power, and other settings. The machine also comes with a comprehensive user manual that provides step-by-step instructions on how to use the machine.

In summary, the Jewelry Laser Welding Machine is a high-quality, precision tool that is essential for jewelers, goldsmiths, and jewelry repair shops. It uses a laser beam to weld and repair jewelry without damaging the surrounding materials. It operates at a laser wavelength of 1064nm, has a laser pulse frequency of 1.0~10.0Hz, and a water cooling system that ensures the laser remains at a constant temperature during operation. The machine has a weight of 35KG, making it compact and easy to move around. It comes in two models, with laser power options of 100W and 200W, and is easy to use with minimal training required.



Features:

  • Product Name: Jewelry Laser Welding Machine
  • Dimension: 520*300*270 Mm
  • Laser Wavelength: 1064nm
  • Max Output Power: 60 W
  • Laser Spot Diameter: 0.1-3mm


Technical Parameters:

Product Name: Jewelry Laser Welding Machine
Max Output Power: 60 W
Dimension: 520*300*270 Mm
Laser Pulse Width: 0.1-10ms
Laser Power: 100W/200W
Laser Type: YAG
Weight: 35KG
Power Supply: 220V/50Hz
Laser Wavelength: 1064nm
Welding Depth: 0.1-3mm
Laser Pulse Frequency: 1.0~10.0Hz Continuously Adjustable


Applications:

The Jewelry Laser Welding Machine utilizes a laser pulse frequency of 1.0~10.0Hz, which is continuously adjustable to suit the specific welding needs of the user. Its water cooling system ensures that the machine operates at optimal temperatures, preventing overheating and prolonging its lifespan. With a laser wavelength of 1064nm and a pulse width of 0.1-10ms, this machine provides a precise and efficient welding process.

The Jewelry Laser Welding Machine is perfect for welding various types of jewelry, including gold, silver, platinum, and stainless steel. Its maximum single pulse energy of 40J/100J allows for deep penetration welding while maintaining the integrity of the jewelry piece. This makes it an ideal choice for repairing broken jewelry or creating new pieces.

This machine is also suitable for various jewelry welding scenarios, such as resizing rings, repairing links, welding clasps, and attaching findings. It is easy to use and allows for precise control of the welding process, ensuring that the jewelry piece is not damaged or deformed during the welding process.

In summary, CKD's Jewelry Laser Welding Machine, model number CW-J4, is a high-quality and efficient machine that is suitable for various jewelry welding applications. Its precise welding capabilities, adjustable pulse frequency, and water cooling system make it an excellent investment for jewelry manufacturers and repair shops. With its maximum single pulse energy of 40J/100J, this machine can handle even the most challenging welding tasks with ease.
