Vertical Automatic Laser Drilling Machine
Used To Open Holes For Gas Stoves
Scope of application
This glass drilling machine is widely used in household appliances , sanitary ware , decoration , technology , optics , Drilling of glass and ceramic products in construction, photovoltaic and other industries .
Specific materials : ordinary glass , ultra white glass , K9 glass , stone British glass , high borosilicate glass , etc
Description
1 .Selected high-quality lasers, vibrating mirror,etc. The core components ensure the high quality and stability of the laser beam.
2 . XYZ axis to achieve different thicknesses. Drilling in different sizes and at any position.
3 . Marble platform: safe and stable, strong and durable. Computer operation: simple and convenient, support a variety of formats.
Technical parameters | |
Laser type | Green pulse laser |
Laser power | 10w , 30w , 45w |
laser wavelength | 532nm |
laser pulse width | 7ns@100KHz |
Laser pulse frequency | 50-500KHz |
Work Size | 800*800mm 800*1000mm |
Drilling Thickness | <20mm |
Drilling Φ | <Φ100mm |
Positioning Accuracy | ±0.02mm |
Chipping | ≤200μm |
Positional accuracy | ±3μm / ±5μm |
Power | AC220V±5%,L+N+E,<3KW |
Dimension | 1560mm × 1750mm × 1750mm / 1900mm ×1800mm × 1900mm |
Weight | 1500kg |
Processing advantage
1 . High quality
laser drilling machine drilling process will not produce mechanical force, will not damage the glass surface, drilling aperture is smooth, no burrs, no cracks, to ensure the quality of drilling.
2 . Flexibility
The laser drilling machine can drill different shapes and sizes according to the needs, and can achieve complex hole design to meet different processing needs.
3 . Environmental protection and energy saving
Laser drilling machines do not need to use traditional mechanical tools, reducing material waste and energy consumption, but also reduce pollution to the environment.
Applicable Industries
|
||
Glass
Optic/UTG/Willow/Brittle/Biomedical Glass
|
Real Estate
Architectural decoration bathroom glass
|
Automobile
Car glass/Instrumentation panel
|
Communication Media
Mobile/Watch /Sapphire cover/ Camera/CCTV Lens
|
Home Appliance
Home appliance glass panel lighting glass
|
New Energy
Photovoltaic glass
|
