Strengthened and non-strengthened glass cutting (mobile phone glass cover , car glass cover , camera glass cover, etc.) , sapphire glass cutting ( mobile phone sapphire cover , camera sapphire glass cover, ｓapphire light bar ( LED light bar ) , etc.) , LCD glass cutting ( abnormal LCD screen inverted R/U/C angle , LCD screen slitting , etc. ) , other optical glass cutting ( filter cutting, mirror cutting, etc., prisms, etc.)
|
Laser type
|
Picosecond Pulsed Laser
|
|
Laser power
|
10W-100W
|
|
Laser wavelength
|
1060nm
|
|
Pulse frequency
|
1Hz-1000kHz
|
|
Cutting speed
|
0-300mm/s adjustable
|
|
Cutting thickness
|
≤10mm
|
|
Cutting accuracy
|
≤±20um,The highest accuracy is ±5um
|
|
X/Y stroke
|
500x650mm
|
|
Weight
|
About 2000KG
|
|
Warranty service
|
1 years
|
|
Power supply
|
AC220V±5%
|
|
Cooling method
|
Water cooling
|
|
Length, width, height
|
1568 / 1550 / 1800(mm)
|
|
Cutting thickness schedule
|
||||
|
Laser power
|
Frequency
|
Cutting thickness
|
Cutting speed
|
|
|
10W
|
100K
|
≤0.7mm
|
≤500mm/s
|
|
|
20W
|
100K
|
≤1.5mm
|
≤500mm/s
|
|
|
30W
|
50K
|
≤4.5mm
|
≤300mm/s
|
|
|
50W
|
20K
|
≤19mm
|
≤120mm/s
|
|
|
80W
|
50K
|
≤10mm
|
≤300mm/s
|
|
Application areas:
This equipment is used for all kinds of glass cutting, smart home display cutting, camera lens laser cutting, coated lens cutting, heterosexual glass laser cutting, LCD screen laser cutting, automobile central control glass cutting, mobile phone glass cover cutting, photovoltaic glass cutting and Glass cutting and drilling, etc., can be widely used in high-precision marking and cutting of glass, drilling and cutting of sapphire, marking/drilling/cutting of ceramics, cutting of LCD/OLED display panels, LED wafer dicing and Cutting and other processing fields. The laser equipment automatically locates and cuts by vision, with high speed and high positioning accuracy. When moving, there is no contact between the stator and the mover, so there is no wear and tear for a long time, and basically no maintenance is required.
SUBSEQUENT SPLIT PROCESSING
1 . Non-strengthened glass : CO2 laser can be used to heat along the cutting line, so that the glass will be heated to produce stress and separate the shards / after cutting , it will be strengthened twice to produce stress shards ;
2 . Tempered glass : After cutting, the self-strengthening stress is released and the splinters are separated automatically ;
3 . LCD screen glass : mechanical pulling , firing pin split / ultrasonic split ;
4 . Filter glass : mechanical knife lobes , etc.;
5 . Camera protection glass : laser cracking or soaking in chemical medicine , etc.
* Whether the equipment needs a C02 laser splitter , please contact our customer service to confirm !
